Description
Power/Displacement 4.7 HP – 3.5 kW/63.4 cm³
Bar length (nose) 46-51 cm, 18”-20”, (replaceable sprocket), 51-61-71 cm, 20″-24″-28″, (stellite)
Chain (pitch x gauge) 3/8”x.058”
Oil Pump automatic, adjustable, zero flow rate at idle speed
Oil/fuel tank capacity 0.45 L/0.80 L
Sound pressure/power level 103.3/112 dB(A)
Lh/rh vibration level 5.3/5.3 m/s²
Dry weight without bar and chain 6.5 kg
